Description
The CZI GL60 Plus Searchlight is based on DJI Payload SDK and compatible with the DJI M300/M350. Powered by DJI Skyport V2.0, the GL60 Plus is super bright, up to 13400LM, with a max lighting area to 1225m². The overall design is ultra-lightweight at only 750g.
The CZI GL60 brings aerial illumination effect of drones during night operations to a whole new level. The DJI M300 spotlight is widely used for night patrols, surveillance, power line inspection, search and rescue, and other night operations.
Features
- Spotlights develop on DJI SDK Payload, compatible with DJI M300/M350/M400 drone.
- Easy to install and use, just plug and play, mount to the gimbal port, just like you install the H20 camera.
- Follow the gimbal camera (H20/H20T) rotation synchronization.
- High power up to 120W, super brightness to 13400LM.
- Non-reflective bowl design, reducing effective brightness loss, with strong light flash mode, silently driving away and indicating direction.
- Imaging-grade optical technology, 4 sets of optical lens groups, 1 group of 4 lenses, 15-degree luminous angle.
Compatibility
DJI Matrice 300
DJI Matrice 350
DJI Matrice 400
In the Box
1 – CZI GL60 Plus Gimbal Searchlight
Specifications
| Model |
GL60 Plus |
| Electrical interface |
DJI SkyPort V2.0 |
| Weight |
750g |
| Size |
126x131x167mm |
| FOV |
15° |
| Voltage |
PSDK 17V+OSDK 24V |
| Total power |
128W |
| LED power |
120W |
| Luminous flux |
13400lm±3%（Power:120W） |
| Light effect |
111.67lm/W（Power:120W） |
| Spot diameter |
13.2m（distance：50m） |
| Probe area |
136m²（distance：50m） |
| Central illuminance |
85Lux（Power:120W；distance：50m） |
| Function mode |
Normally on: 120W; 60W |
| Pan tilt rotation range |
Pitch: – 95 ° ~ + 20 ° < br / > Horizontal: ± 90 ° |
| PTZ design scope |
Pitch: – 100 ° ~ + 25° < br / > Horizontal: ±100° < br / > Rolling: – 90°～+ 60° |
| Working temperature |
-15°C~+50°C |
