Description
DJI Matrice 30 Enterprise | Mighty, Versatile, Transportable
The DJI Matrice 30 Enterprise integrates multiple high-performance sensors into one single camera payload, is controlled with an ingenious redesigned remote control and runs on upgraded Pilot 2 software, which significantly improves the flight experience. The M30 model offers much more power, endurance and capability for rugged professional uses, while its size makes it ideal for easy transportation and fast setup.
Apart from its outstanding performance and new format, the DJI M30 allows professionals to fly and perform beyond their immediate surroundings. It integrates smoothly with the new DJI FlightHub 2 fleet management cloud-based software and the DJI Dock for collaboration with remote and unattended operations, bringing efficiency innovation to various industries.
Key Features:
- Weather Resistance: IP55 rating for the aircraft, P54 rating for RC Plus, -20°C to 50°C, 15m/s wind resistance
- DJI RC Plus Compatibility: 7 inch high-brightness screen, dual remote controller, option, 4 antennas for enhanced transmission, swappable battery
- Powerful Hybrid Payload: Significantly improved zoom capability, laser range finder (enabling smart features), built-in FPV camera
- Quick Deployment: 41min flight time, hot-swappable dual batteries, 3.77kg in weight, fits in a backpack
Best in Class Hybrid Data Collection
The M30 model integrates a 48 megapixel 1/2” CMOS sensor zoom camera with 5×~16× optical and 200× digital zoom, a 12 megapixel wide-angle camera, 8k photo 4K/30 fps video resolution, and a laser rangefinder which can give the precise coordinates of objects up to 1,200 meters away.
A Robust, Safe and Reliable Aerial Platform with Extraordinary Resistance
With IP55 ingress protection, the M30 offers outstanding performance in harsh environments, in heavy rains, high winds, high altitudes, even in icy and snowy conditions and extreme temperatures from -20° C to 50° C.
The DJI M30 also offers an improved first-person view pilot camera for low light conditions, built-in redundancies and backup systems, three-propeller emergency landing, a Health Management System, and six-way obstacle avoidance sensors enabling the pilot to focus on the mission. Its four-antenna OcuSync 3 Enterprise transmission ensures a strong redundancy, and it supports LTE link backup, in the face of complex terrain and working conditions.
Unlike other commercial drones, the DJI M30 adopts a foldable integrated lightweight design (3.7 kg take-off weight) that is easy to unfold, store and carry anywhere. Its new self-heating TB30 battery design can support at least 400 charge cycles and allows a 41-minute flight time. Its smart BS30 charging case allows quick battery charging from 20% to 90% in 30 minutes. The M30 also has a new self-locking system and can be folded by just pressing a button. This makes it the fastest, easiest high-performance DJI Enterprise drone to set up.
In the Box
1 – DJI Matrice 30
2 – TB30 Flight Battery
1 – BS30 Battery Station
1 – DJI RC Plus
1 – DJI Pilot 2
DJI FlightHub 2 (3 month subscription)
Specifications
Key Specs
| Maximum Flight Time | 41 Minutes |
| Rotor Configuration | 4 |
| Image Sensor | Size-Unspecified CMOS |
| Still Image Support | Yes |
| Control Method | Included Transmitter |
| Maximum Operating Distance | Not Specified by Manufacturer |
| Mobile App Compatible | No |
| Weight | 8.8 lb / 3998 g (Maximum for Takeoff) |
Performance
| Maximum Wind Resistance | 33.6 mph / 54.1 km/h |
| Flight Ceiling | 4.3 Miles / 7000 m |
| Maximum Flight Time | 41 Minutes |
| Maximum Hover Time | 36 Minutes |
| Maximum Tilt Angle | 35° |
| Hovering Accuracy | Vision Positioning Vertical: ±0.3′ / 0.1 m GNSS Vertical: ±1.6′ / 0.5 m Vision Positioning Horizontal: ±1.0′ / 0.3 m GNSS Horizontal: ±4.9′ / 1.5 m RTK Vertical: ±0.3′ / 0.1 m RTK Horizontal: ±0.3′ / 0.1 m |
| Maximum Angular Velocity | 150°/s (Pitch) 100°/s (Yaw) |
Aircraft
| Rotor Configuration | 4 |
| Motor Model | 3511 |
| Propeller Model | 1671 |
| Operating Temperature | 12 to 82°F / -20 to 50°C |
Camera
| Image Sensor | Size-Unspecified CMOS |
| Sensor Resolution | Effective: 48 Megapixel |
| Focal Length | 21 to 75mm / 113 to 405mm (35mm Equivalent) |
| Maximum Aperture | f/2.8 to 4.2 |
| Minimum Focus Distance | 16.4′ / 5 m |
| Broadcast Resolution | No |
| Still Image Support | Yes |
Gimbal
| Number of Axes | 3: Pitch (Tilt), Roll, Yaw (Pan) |
| Rotation Range | Controllable Range Pitch (Tilt): 165° (-120 to 45°) Roll: 180° (-90 to 90°) |
Remote Controller / Transmitter
| Control Method | Included Transmitter |
| Operating Frequency | 2.4 GHz (2.400 to 2.484) 5.8 GHz (5.725 to 5.850) |
| Maximum Operating Distance | Not Specified by Manufacturer |
| Transmitter Power | 2.4 G: 33 dBm 5.8 G: 33 dBm |
| Battery Chemistry | Lithium-Ion |
| Battery Capacity | 6500 mAh |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Mobile App Compatible | No |
| Built-In Display Size / Type | 7.02″ Non-Touchscreen LCD |
| Display Resolution | 1920 x 1200 |
| Display Brightness | 1200 nits / cd/m2 |
| Operating Temperature | -4 to 122°F / -20 to 50°C |
General
| GNSS Support | GPS, GLONASS, BeiDou, Galileo |
| Remote ID | No |
| Diagonal Size | 26.3″ / 668 mm |
| Overall Dimensions | 23.0 x 8.5 x 18.5″ / 585.0 x 215.0 x 470.0 mm (Unfolded) 8.5 x 7.7 x 14.4″ / 215.0 x 195.0 x 365.0 mm (Folded) |
| Weight | 8.8 lb / 3998 g (Maximum for Takeoff) |
