Description
The rear-mounted DJI SDR Module adds 902-928 MHz and 1.4 GHz bands to the DJI RC Plus 2 Enterprise Enhanced Controller, boosting penetration and range in dense urban or forested terrain. Designed for environments with high interference or extended range requirements, the DJI SDR Module ensures more stable and secure video and data links. It’s especially valuable for long-range missions, critical infrastructure inspections, and public safety operations.
Compatibility
DJI RC Plus 2 Enterprise Enhanced Remote Controller
DJI Matrice 400 Series
In the Box
1 – DJI RC Plus 2 sub2G SDR Module
Specifications
Supported Bands: 902–928 MHz (FCC/ISM) / 1.430–1.444 GHz (SRRC)
Channels / Streams: 2 T × 2 R (MIMO)
Antenna Type: High-gain monopole array, vertically polarized
Status Indicator: Tri-color LED shows link state & band in real time
Mounting: Rear slide-in bay, captive screws (included)
Operating Temp: –4 °F – 122 °F (–20 °C – 50 °C)
Dimensions / Weight: 56 × 45 × 20 mm / ≈ 35 g
